Blackmagic Design ATEM Mini Extreme ISO G2
Flagship eight input switcher with Thunderbolt, CFexpress recording, XLR and MADI audio and full ISO capture.
SKU: BLA-SWATEMMINICEXTISOG2
AvailabilityIn stock, ready to dispatch
In stock and dispatched from our Johannesburg warehouse.
ShippingNationwide courier
We deliver across South Africa with reliable courier partners. Shipping is calculated at checkout.
Bulk & trade ordersGet a quote
Buying in volume? Contact us for trade and bulk pricing.
Finance optionsStitch · Payflex · Float
The Blackmagic Design ATEM Mini Extreme ISO G2 is the most advanced model in the ATEM Mini family, combining eight HDMI inputs, professional XLR and MADI audio, Thunderbolt and high speed recording in one compact live production switcher. It is designed for broadcasters who need scale, clean recordings and professional connections in a desktop unit.
The second generation ISO model records all eight inputs to a fast CFexpress card and adds a Thunderbolt connection that handles fill and key playback, capture, Ethernet access to storage and power over a single computer cable. A 10G Ethernet port supports high bandwidth recording to network storage.
Key Features
- Eight standards converted HDMI inputs with three independent HDMI outputs.
- Records all eight HDMI inputs as H.264 files at up to 70 Mb per second to CFexpress.
- Thunderbolt connection for fill and key out, capture, Ethernet to storage and power.
- Professional audio with two XLR combo inputs and 32 channel MADI input.
- 26 input audio mixer with Fairlight EQ, compressor, gate and limiter.
- Four upstream keyers, two downstream keyers, two DVEs and two media players.
- Built in streaming engine and configurable multiview up to 16 views.
Ideal For
- Professional multi camera broadcast and streaming.
- Houses of worship with large audio and camera setups.
- Live events that are re edited and archived afterwards.
- Sports, esports and stage productions.
- Studios needing Thunderbolt capture and CFexpress recording.
Specifications
- 8 x HDMI type A inputs, 10-bit HD.
- 3 x HDMI program outputs.
- 8 x HDMI ISO recordings to CFexpress at up to 70 Mb per second.
- Thunderbolt plus 1 x 10G Ethernet for recording.
- 2 x XLR combo inputs with phantom power and 32 channel MADI.
- 120W max power consumption.
Available from Prosales, South Africa's authorised Blackmagic Design reseller and integrator.
| Video Inputs | 8 x HDMI type A, 10-bit HD |
| Video Outputs | 3 x HDMI program outputs |
| Supported Formats | 720p50 to 60, 1080p23.98 to 60, 1080i50 to 60 |
| ISO Recording | 8 x HDMI inputs as H.264 .mp4 up to 70 Mb/s |
| Recording Media | CFexpress card slot |
| Thunderbolt | Fill key out, video in, Ethernet to storage and power |
| Network | 1 x 10G Ethernet for recording |
| Audio Inputs | 2 x XLR combo with phantom power, 32 channel MADI |
| Audio Mixer | 26 input x 2 channel with Fairlight EQ and dynamics |
| Keyers | 4 upstream and 2 downstream |
| DVEs | 2 |
| Media Players | 2 |
| Multiview | Configurable 4, 7, 10, 13 or 16 views |
| Power | 120W max |
| Included | Unit and external 12V power supply |
Thunderbolt In One Cable
A single Thunderbolt connection handles fill and key playback, capture, Ethernet access to the CFexpress storage and trickle power. It is the cleanest way to link the switcher to a computer.
Record All Eight Inputs
Every one of the eight HDMI inputs records as its own H.264 file at up to 70 Mb per second to a fast CFexpress card. A 10G Ethernet port adds high bandwidth recording to network storage.
Professional Broadcast Audio
Two XLR combo inputs with phantom power and a 32 channel MADI input bring professional sound into the mix. The 26 input Fairlight mixer adds EQ, compressor, gate and limiter across every channel.
