Blackmagic Design DeckLink Quad 2
PCIe card with eight independent bidirectional 3G-SDI mini DIN channels for capture and playback up to 1080p60.
SKU: BLA-BDLKDVQD2
You are on the list. We will email you the moment it is back.
Something went wrong. Please try again.
1-Year Warranty · Authorised SA Distributor · Nationwide Shipping
AvailabilityMade to order
Currently made to order. Contact us for lead times.
ShippingNationwide courier
We deliver across South Africa with reliable courier partners. Shipping is calculated at checkout.
Bulk & trade ordersGet a quote
Buying in volume? Contact us for trade and bulk pricing.
Finance optionsStitch · Payflex · Float
The Blackmagic Design DeckLink Quad 2 is a high density PCI Express capture and playback card featuring eight independent 3G-SDI mini DIN channels. Each of the eight connectors is bidirectional and can be switched between capture and playback, giving you any combination of up to eight channels in SD and HD up to 1080p60.
With eight fully independent channels on a single card, it is an ideal solution for broadcast playout servers, multi channel ingest and large software based switching systems.
Key Features
- Eight independent 3G-SDI mini DIN channels
- Each connector switchable between capture and playback
- SD and HD formats up to 1080p60
- 16 channels of embedded SDI audio
- Supports ProRes, DNxHD and uncompressed 10-bit 4:2:2 and 4:4:4
- PCI Express 8-lane Generation 3 interface
- Compatible with Mac, Windows and Linux
Ideal For
- Broadcast playout and ingest servers
- Multi channel capture and playback
- Large scale software based switching
- Channel branding and master control
- Live event and studio infrastructure
Specifications
- 8 x bidirectional 3G-SDI mini DIN connectors
- Formats up to 1080p60 in SD and HD
- 16 channels of embedded audio
- 12-bit SD and HD
- PCI Express 8-lane Generation 3 (8 and 16-lane slots)
- Mac, Windows and Linux support
Available from Prosales, South Africa's authorised Blackmagic Design reseller and integrator.
| SDI Channels | 8 x bidirectional 3G-SDI mini DIN |
| Configurability | Each channel capture or playback |
| Formats | SD and HD up to 1080p60 |
| Colour Depth | 12-bit SD and HD |
| Audio Channels | 16 embedded |
| Uncompressed | 10-bit 4:2:2 and 4:4:4 |
| Codecs | ProRes, DNxHD supported |
| PCIe Interface | PCIe 8-lane Generation 3 (8 and 16-lane slots) |
| Connectors | Mini-BNC DIN |
| System | macOS, Windows, Linux |
Eight Independent Channels
Eight 3G-SDI connectors on a single card, each switchable between capture and playback. Build any combination of up to eight independent channels in SD or HD.
High Density For Servers
Packs eight channels into one PCIe slot, ideal for broadcast playout servers, multi channel ingest and large software based switching systems.
Broadcast Quality
Supports ProRes, DNxHD and uncompressed 10-bit 4:2:2 and 4:4:4 video with 16 channels of embedded audio for professional capture and playback.
