Blackmagic Design Micro Studio Camera 4K G2 (body only)
Tiny broadcast quality 4K studio camera with 12G-SDI, an active MFT mount and 13 stops of dynamic range.
SKU: BLA-CINSTUDMFT/UHD/MRG2
Pay over 2 to 6 interest-free instalments with Stitch at checkout.
1-Year Warranty · Authorised SA Distributor · Nationwide Shipping
AvailabilityOnly 2 left
In stock and dispatched from our Johannesburg warehouse.
ShippingNationwide courier
We deliver across South Africa with reliable courier partners. Shipping is calculated at checkout.
Bulk & trade ordersGet a quote
Buying in volume? Contact us for trade and bulk pricing.
Finance optionsStitch · Payflex · Float
The Blackmagic Micro Studio Camera 4K G2 is a tiny, broadcast quality studio camera designed for multi camera live production. Despite its small size, it features a Four Thirds 4K sensor, 13 stops of dynamic range and a 12G-SDI connection for clean, uncompressed Ultra HD images.
An active MFT lens mount with iris, focus and zoom control, full remote operation over SDI, and the ability to record Blackmagic RAW direct to a USB-C disk make it ideal for everything from live switching to point of view rigs. The advanced Blackmagic OS powers on almost instantly.
Key Features
- Four Thirds 4K sensor with 13 stops of dynamic range
- 12G-SDI Micro BNC output for uncompressed Ultra HD up to 2160p60
- Active MFT mount with iris, focus and zoom control
- Records Blackmagic RAW to USB-C disks
- Full remote camera and lens control over SDI
- Dual native ISO for clean low light images
- Compact body ideal for tight rigging positions
Ideal For
- Multi camera live production and switching
- Broadcast studios and houses of worship
- Point of view and remote camera positions
- Concerts and live events
- Drone and gimbal mounted broadcast work
Specifications
- Sensor: Four Thirds, 17.78mm x 10mm
- Resolution: 3840 x 2160 Ultra HD up to 60 fps
- Lens mount: Active MFT
- SDI: 1 x 12G-SDI in, 1 x 12G-SDI out (Micro BNC)
- HDMI: 1 x HDMI Type A up to 1080p60
- Recording: Blackmagic RAW to USB-C
- Power: External 12V DC 36W supply
Available from Prosales, South Africa's authorised Blackmagic Design reseller and integrator.
| Sensor | Four Thirds, 17.78mm x 10mm |
| Resolution | 3840 x 2160 Ultra HD |
| Dynamic range | 13 stops |
| Max frame rate | 60 fps |
| Lens mount | Active MFT |
| SDI output | 1 x 12G-SDI Micro BNC |
| SDI input | 1 x 12G-SDI Micro BNC |
| HDMI output | 1 x HDMI Type A up to 1080p60 |
| Recording | Blackmagic RAW to USB-C disk |
| Control | Blackmagic Control Protocol over SDI, REST API |
| Power | External 12V DC 36W supply |
| Power draw | 18W to 25W |
| Operating temperature | 0 to 40 degrees Celsius |
Big Image, Tiny Body
A full Four Thirds 4K sensor with 13 stops of dynamic range fits into a remarkably small camera. It slots into rigging positions where a full size studio camera simply cannot go.
Built For Live Production
The 12G-SDI connection carries clean uncompressed Ultra HD up to 2160p60. You can control the camera, lens, iris and focus remotely over a single SDI cable from your switcher.
Record And Control Anywhere
Capture Blackmagic RAW direct to a USB-C disk for isolated recordings of every camera. The active MFT mount gives full iris, focus and zoom control on supported lenses.
