Blackmagic Design ATEM Micro Camera Panel
Portable hardware camera control panel with broadcast CCU controls for up to 8 cameras over Bluetooth or USB-C.
SKU: BLA-SWPANELCCU1
1-Year Warranty · Authorised SA Distributor · Nationwide Shipping
AvailabilityOnly 1 left
In stock and dispatched from our Johannesburg warehouse.
ShippingNationwide courier
We deliver across South Africa with reliable courier partners. Shipping is calculated at checkout.
Bulk & trade ordersGet a quote
Buying in volume? Contact us for trade and bulk pricing.
Finance optionsStitch · Payflex · Float
The ATEM Micro Camera Panel is a portable, hardware camera control unit that brings high end broadcast CCU controls to compact live production setups. It lets you adjust iris, pedestal, gain, white balance, shutter and more for up to 8 cameras from a single panel.
Connecting to ATEM Software Control over Bluetooth 5.1 LE or USB Type-C, the panel features a precision three-axis joystick and assignable camera select buttons, with a built-in rechargeable battery for true portability.
Key Features
- Hardware CCU style control for up to 8 cameras from one compact panel
- Three-axis joystick for smooth iris, pedestal and master black control
- Connects via Bluetooth 5.1 LE or USB Type-C to ATEM Software Control
- Internal rechargeable battery delivering a minimum of 3 hours use
- White and black balance setup plus flare control via modifier key
- Five recallable scenes per camera for instant look matching
Ideal For
- Live event and multi-camera broadcast production
- Houses of worship and theatre productions
- Sports and corporate live streaming
- Studio and OB van camera shading
- Portable field productions needing battery power
Specifications
- Controls up to 8 cameras
- USB Type-C and Bluetooth 5.1 LE connectivity
- Power usage 4 W max, minimum 3 hours battery life
- Gain range -12dB to +32dB, white balance 2500K to 10,000K
- Operating temperature 5 to 40 degrees C
Available from Prosales, South Africa's authorised Blackmagic Design reseller and integrator.
| Cameras controlled | Up to 8 |
| Computer interface | USB Type-C |
| Wireless | Bluetooth 5.1 LE |
| Camera selection | 8 x assignable NKK buttons |
| Joystick | 1 x three-axis |
| Iris control | Auto Iris On, Coarse, CLS f32 to f1.2 |
| Gain range | -12dB to +32dB |
| Shutter range | 1/24 to 1/2000 |
| White balance | 2500K to 10,000K |
| ND filters | 0, 2, 4, 6 |
| Recallable scenes | 5 per camera |
| Power | Internal battery plus USB-C, 4 W max |
| Battery life | Minimum 3 hours |
| Operating temperature | 5 to 40 degrees C |
| Included | Panel, USB-C cable, welcome wallet |
Broadcast CCU Control
Adjust iris, pedestal, gain, white balance and shutter for up to 8 cameras from a single panel. Real hardware controls give you the precise, tactile feel of a full broadcast camera shading desk.
Wireless and Portable
Connect to ATEM Software Control over Bluetooth 5.1 LE or USB Type-C. The internal rechargeable battery delivers a minimum of 3 hours, so you can shade cameras anywhere without cables.
Precision Three-Axis Joystick
A smooth three-axis joystick handles iris and master black with fine accuracy. Five recallable scenes per camera let you match looks instantly across a multi-camera shoot.
