Blackmagic Design ATEM Micro Camera Panel

The ATEM Micro Camera Panel is a portable, hardware camera control unit that brings high end broadcast CCU controls to compact live production setups. It lets you adjust iris, pedestal, gain, white balance, shutter and more for up to 8 cameras from a single panel.

Connecting to ATEM Software Control over Bluetooth 5.1 LE or USB Type-C, the panel features a precision three-axis joystick and assignable camera select buttons, with a built-in rechargeable battery for true portability.

Key Features

• Hardware CCU style control for up to 8 cameras from one compact panel
• Three-axis joystick for smooth iris, pedestal and master black control
• Connects via Bluetooth 5.1 LE or USB Type-C to ATEM Software Control
• Internal rechargeable battery delivering a minimum of 3 hours use
• White and black balance setup plus flare control via modifier key
• Five recallable scenes per camera for instant look matching

Ideal For

• Live event and multi-camera broadcast production
• Houses of worship and theatre productions
• Sports and corporate live streaming
• Studio and OB van camera shading
• Portable field productions needing battery power

Specifications

• Controls up to 8 cameras
• USB Type-C and Bluetooth 5.1 LE connectivity
• Power usage 4 W max, minimum 3 hours battery life
• Gain range -12dB to +32dB, white balance 2500K to 10,000K
• Operating temperature 5 to 40 degrees C

Available from Prosales Broadcast, South Africa's authorised Blackmagic Design reseller and integrator.
