Blackmagic Design ATEM 4 M/E Constellation IP Plus
Large format SMPTE-2110 native 4 M/E switcher with 64 inputs, 64 outputs, 100G Ethernet and full IP redundancy.
SKU: BLA-SWATEMSCN2/3ME4/IP/P
AvailabilityIn stock, ready to dispatch
In stock and dispatched from our Johannesburg warehouse.
ShippingNationwide courier
We deliver across South Africa with reliable courier partners. Shipping is calculated at checkout.
Bulk & trade ordersGet a quote
Buying in volume? Contact us for trade and bulk pricing.
Finance optionsStitch · Payflex · Float
The ATEM 4 M/E Constellation IP Plus is the larger member of the Constellation IP family, doubling the connectivity to 64 inputs and 64 outputs while remaining fully SMPTE-2110 native over 100G Ethernet. It is built for the biggest live productions that need huge source counts and full IP redundancy.
Sixteen sets of 100G QSFP28 connections carry redundant SMPTE-2110 video across dual networks, giving facilities a flexible, software defined production core in a single 3 rack unit chassis.
Key Features
- 4 M/E live production switcher with 64 inputs and 64 outputs
- Fully SMPTE-2110 native with redundant SMPTE-2022-7 delivery
- 16 x 100G QSFP28 Ethernet connections across dual networks
- 16 ATEM Advanced Keyers and 12 DVEs from 2 SuperSource processors
- 4 customisable multi-views and a 132 channel audio mixer
- Two internal redundant power supplies for mission critical use
Ideal For
- Major broadcast facilities and large outside broadcast trucks
- High source count live sports and events
- IP infrastructure built on SMPTE-2110 and 2022-7
- Productions mixing HD and Ultra HD signals
- Network and studio control rooms
Specifications
- 64 inputs and 64 outputs over 100G Ethernet
- 16 advanced keyers and 12 DVEs
- HD and Ultra HD up to 2160p60
- Two internal 100 to 240V AC redundant power supplies
- 3 rack unit chassis
Available from Prosales, South Africa's authorised Blackmagic Design reseller and integrator.
| Switcher type | 4 M/E live production switcher |
| Inputs and outputs | 64 inputs and 64 outputs |
| Network | Fully SMPTE-2110 native with SMPTE-2022-7 redundancy |
| Ethernet connectors | 16 x 100G QSFP28 |
| Advanced keyers | 16 ATEM Advanced Keyers |
| Multi-views | 4 customisable multi-views |
| DVEs | 12 DVEs with 2 SuperSource processors |
| Audio mixer | 132 channel with Fairlight Live |
| HD formats | 720p, 1080i and 1080p up to 60 |
| Ultra HD formats | 2160p up to 60 |
| Media pool | 64 stills and 4 clips |
| Colour | 10-bit 4:2:2 |
| Power | Two internal 100 to 240V AC redundant supplies |
| Rack size | 3 rack units |
| Software | ATEM Software Control for macOS and Windows |
Huge IP Connectivity
With 64 inputs and 64 outputs carried over 16 sets of 100G QSFP28 connections, the Plus model handles the largest live productions while staying fully SMPTE-2110 native.
Full Redundancy
All IP video connections support SMPTE-2022-7 redundant delivery across dual networks, and two internal power supplies keep the switcher running through any single failure.
Powerful Processing
Sixteen advanced keyers, 12 DVEs from 2 SuperSource processors and a 132 channel Fairlight audio mixer deliver enormous creative capability in a single 3 rack unit chassis.
